Core advantages
Robust and reliable, with intelligent protection
304L stainless steel one-piece molding
Compared with ordinary 304 stainless steel, 304L has a lower carbon content and extremely strong resistance to intergranular corrosion. It can resist the corrosion of fire-fighting foam, seawater and chemical agents for a long time, is not afraid of acidic and alkaline environments, and its service life is extended by more than 50%.
Automatic monitoring nozzle system
It is equipped with a high-sensitivity sensor to monitor the injection status and Angle in real time and automatically feed back to the control terminal. Alarm immediately in case of unexpected deviation or blockage to ensure the continuous effectiveness of fire-fighting operations.
Ultra-wide-angle coverage, no blind spot protection
Vertical travel of 135° (from -45° dive to +90° elevation Angle), easily handling ground flowing fires or high-altitude fire points. With a horizontal rotation of 350°, it leaves only a 10° safety blind zone, achieving nearly panoramic coverage.
Dual-mode injection, one-click switching
Electronic control for quick switching:
✅ Direct injection mode - strong impact force, extinguishing concentrated fire sources, cooling equipment
✅ Mist spray mode - large coverage area, blocking radiant heat and diluting chemical vapors
List of Technical Parameters
| Model Number | PSKD50EX-A | PSKD60EX-A | PSKD80EX-A |
| Flow Rate | 3000 LPM | 3600 LPM | 4800 LPM |
| Working Pressure | 8.5 Bar | 9.5 Bar | 10.5 Bar |
| Max. Reach | 75 meters | 75 meters | 80 meters |
| Max. Fog Angle | 120° | ||
| Max Range Of Motion | -45°to +90° Vertically,360° Rotation,other degree available | ||
| Turing speed | 7°/Second rotation,7"/second vertical | ||
| Power supply | DC 24V is standard | ||
| Power Consumption | Max. 195W | ||
| Waterway size | 2.5"(50mm) | 3"(50mm) | 3"(65mm) |
| Monitor Outlet | 2.5"(50mm)NH | ||
| Monitor lnlet | Flange 4"ANSl 150# is standard,other size and standard available | ||
| Material |
Monitor-ss304 stainless steel is standard,ss316 is available Nozzle -Hard coated anodized aluminium alloy |
||
| Control system | ICS-EX-01 or VMCS-01 | ||
Application scenarios
Petrochemical storage tank area - Explosion-proof design matches high-risk areas, and the mist spray mode effectively isolates vapor clouds
Port fire boats/docks - Made of 304L material, they are resistant to seawater corrosion and can quickly suppress ship fires with large flow rates
Airport tarmac - Remote control ensures rescue safety, direct injection mode precisely combats aviation fuel fires
Power substation - DC power supply compatible emergency power generation vehicle, insulating mist water to extinguish electrical fires
Tunnel warehouse - Wide-angle rotation covers narrow and long Spaces, and automatic monitoring reduces the risk of personnel entry
Why choose?
Outstanding life-to-cost ratio
304L stainless steel structure, maintenance-free, no need to replace the gun body for long-term use.
01
Integrated control
Compatible with existing fire alarm systems, supporting direct connection of PLC/ central control room.
02
Safety redundancy design
In emergency situations, the manual valve can be switched, providing dual protection for continuous spraying.
03
Flexible configuration
Customize nozzle diameters based on on-site water pressure and pipelines to provide a solution for maximizing flow.
04
FAQ
Q: There are 3000, 3600, and 4800 LPM traffic options available. How should we decide? Is it true that the greater the traffic, the better?
A: Not at all. Selecting the flow rate requires a scientific match with the capacity of your fire pump and the supply of your pipeline. We suggest:
- 3000 LPM: Suitable for factory renovation projects where the pressure of the existing water supply network is relatively low (such as 0.8-1.0MPa).
- 3600 LPM: It is the "gold standard" for most new petrochemical projects, balancing fire extinguishing efficiency with equipment costs.
- 4800 LPM: Specifically designed for large oil tanks and liquefied natural gas terminals, it requires the matching of high-power fire pumps and thick-diameter main pipes.
Q: The vertical range is from -45° to +90°. What's the use of this -45° downward?
A: This design is aimed at the key scenarios in real fires:
- Extinguishing ground flowing fires: After a petrochemical material leakage catches fire, it often spreads along the ground. A -45° depression Angle can precisely cover the fuel surface with foam.
- Cooling adjacent tanks: When adjacent storage tanks are threatened by thermal radiation, downward spraying can continuously cool the weak areas beneath them.
- Clearing obstacles: Strong water flow can wash away scattered fire spots or obstacles on the fire extinguishing passage.
Q: How are direct spray and mist spray modes specifically used in actual fire extinguishing?
A: This is a tactical-level switch:
- Direct spray (direct current) : Like "fire-fighting water arrows", it is used for strong attacks and close combat. For instance, concentrating water flow to cut the base of the flame or conducting targeted and powerful cooling on the high-temperature tank wall.
- Mist spray (flowering) : Forms a water mist barrier for defense and coverage. For instance, an insulating screen can be formed between rescue workers and the fire scene, or the volatile toxic gases can be diluted and dispersed. It can be switched with one click through the remote control to achieve flexible tactical combinations.
Protecting your assets starts with choosing professional fire-fighting equipment.
