One gun with multiple functions: Three modes (direct current, spray, and off) can be switched with one button, suitable for complex conditions in fire scenes.
Global standard: Compatible with 6 countries' standard interfaces (Storz/American/BS336/Gost/Machino/French).
Super-range Jetting: The minimum jetting distance is 32 meters, with outstanding penetration power.
Lightweight design: The all-aluminum body weighs only 2.2kg, allowing a single person to operate it with one hand.
Three practical scenario demonstrations
🏢
High-rise building fire
- Direct current mode - 32-meter long-range direct attack on the fire point.
- The water mist mode forms a protective barrier, shielding the rescue personnel as they advance.
🔥
Chemical fire
- Precise water mist dilutes toxic gases.
- Anti-corrosion coating resists chemical erosion.
🌲
Forest fire scene
- High-flow mode, 13 liters per second, rapidly suppresses the fire.
- The ergonomic grip is paired with a quick-release interface, making it highly mobile in the field.
Parameter Details
| Characteristics | Parameters |
| Interface configuration | Standardly equipped with 1.5''/2''/2.5'' threaded interfaces, and optional 6-country quick interfaces are available |
| Pressure adaptation | Maintains optimal atomization effect under 100 PSI normal pressure |
| Flow control | Infinite adjustment knob, precisely controlling from fine mist to column-like water flow |
| Maximum flow | In the fully open state, it can reach a flow rate of 13L/S (with a 2.5'' interface) |
| Material and Process | Aluminum alloy anodizing + shock-proof rubber sheath |
| Operating temperature | -30℃ to 180℃. Can be used normally in extreme environments |
The 5 most concerned issues of the purchaser
Q1: Do we need tools for interface switching?
→ No tools are required. The interface can be changed within 30 seconds.
Q2: Will it leak after long-term high-pressure use?
→ Precision bearings + sealed structure, zero leakage even under 150 PSI pressure for 8 consecutive hours.
Q3: Is it suitable for retrofitting old fire trucks?
→ We offer a complete set of adapters, which are compatible with most mainstream fire trucks worldwide produced after 1990.
Q4: What is the minimum water pressure requirement?
→ The actual measurement shows that 65 PSI is sufficient for stable atomization, making it suitable for remote areas with insufficient water pressure.
Q5: What about the maintenance cost?
→ With a modular design, the wear-prone parts can be replaced separately, resulting in a 60% lower maintenance cost compared to traditional models.
When your team holds this water gun in the fire scene -
What they are grasping is not a tool, but the power of choice.
They can choose to use the column-like water flow to penetrate the thick smoke, or to use the water mist to build a barrier of life.
What we offer is never metal fittings, but the confidence to ensure that every firefighter can return home safely.
